Telescopic Type Davit Device With Marine Certificate

Availability:
  • DEYUAN

Telescopic Type Davit Device With Marine Certificate

1.Item:Fast rescue boat landing device.

2.Product standard:LSA,IMO MSC.81(70).

3.Working load:42KN~70KN.

Telescopic type davit device

The telescopic device is used for hanging realted boat on board.The device arm could be moveable horizontally,also,

which could hang the boat from the parking lacation to water position,also recovery it from the water position to the

 parking location,and the lifting device could make vertical movement of the boat.Vertical movement and horizontal

movement can be in independently controlled manner.This device meets the 1974 International Convention for the safety

of life at sea,International life-saving appliance regulations(LSA)&IMO,MSC.81(70) and other regulatory requirements.

type

Max working load

Max recover load

Breath

Height

Suitable winch

Suitable boat

M

TD65

65KN

42 KN

3650

4500

D50S/D50Z

BCF-6.5

TD80

80 KN

40 KN

4000

4850

D63S/D63Z

BCF-7.5

TD120

120 KN

60 KN

4700

5500

D80S/D80Z

BCF-8.5

TD150

150 KN

65 KN

5300

5600

D100S/D100Z

BCF-9.5

TD180

180 KN

70 KN

5600

5700

D125S

BCF-10.3
