DEYUAN
China (Mainland)
DEYUAN
SWCB series
Sewage treatment plant
Sewage treatment plant
Export standard packaging.
About 20 days
Waste Water Processor :
The regulation specifies the requirements of constitution, main function, design, manufacture, test and delivery for SWCB-10 type Sewage Treatment Plant (hereinafter to be referred as SWCB-10 type Device).
1. Model: SWCB-10 Type
2. Quantity: 1 set/vessel
3. Capacity: Rated capacity: 10persons
4. Max capacity: 12persons
5. Emission index: BOD5 equal or smaller than50mg/l, SS equal or smaller than50mg/l, Coliform group equal or smaller than250/100ml, PH =6~9
6. Voltage: 400V/ 50Hz /3Φ
7. Power: 1.5KW
2.8 Outline dimension: L×W×H=1300×1170×1380mm
2.9 Dry weight/wet wight: 1050/2210 kg
1. Complete machine is provided with SWCB-10 type device one set, the main components include:
| No. | Name | Model | Amount | Remarks |
| 1 | The device base | 321DF-10-01 | 1set | Material: Q235-B |
| 2 | Main body | 321DF-10-02 | 1set | Material: Q235-B |
| 3 | Cutting pump | 0.5CWF-8 | 1set | Marine electric machine |
| 4 | Electric control box | 321DF-1-00YL | 1set | The main components select Schneider product |
| 5 | Air pump | CYBW-10 | 1set | Marine electric machine |
| 6 | Dosing pump | | 1set | |
| 7 | Piping accessory of device | | 1set | |
Waste Water Processor :
The regulation specifies the requirements of constitution, main function, design, manufacture, test and delivery for SWCB-10 type Sewage Treatment Plant (hereinafter to be referred as SWCB-10 type Device).
1. Model: SWCB-10 Type
2. Quantity: 1 set/vessel
3. Capacity: Rated capacity: 10persons
4. Max capacity: 12persons
5. Emission index: BOD5 equal or smaller than50mg/l, SS equal or smaller than50mg/l, Coliform group equal or smaller than250/100ml, PH =6~9
6. Voltage: 400V/ 50Hz /3Φ
7. Power: 1.5KW
2.8 Outline dimension: L×W×H=1300×1170×1380mm
2.9 Dry weight/wet wight: 1050/2210 kg
1. Complete machine is provided with SWCB-10 type device one set, the main components include:
| No. | Name | Model | Amount | Remarks |
| 1 | The device base | 321DF-10-01 | 1set | Material: Q235-B |
| 2 | Main body | 321DF-10-02 | 1set | Material: Q235-B |
| 3 | Cutting pump | 0.5CWF-8 | 1set | Marine electric machine |
| 4 | Electric control box | 321DF-1-00YL | 1set | The main components select Schneider product |
| 5 | Air pump | CYBW-10 | 1set | Marine electric machine |
| 6 | Dosing pump | | 1set | |
| 7 | Piping accessory of device | | 1set | |
