HG20593-97 Raised Face 16bar Varnish Plate Flange

Inquire Add to Basket

  • Carbon Steel

  • HG20593-97

  • China (Mainland)

  • Standard

  • Export standard packaging.

  • Depends on your order quantity.



Plate Flange :

HG20593-97 Raised Face 16bar Varnish Plate Flange:

Product Description:

HG20593-97 Chemical standard 16bar Varnish Plate Flange.

16bar Plate Flange Outside Diameter:14mm-530mm.

16bar Bolt Hole Spacing Varnish Plate Flange:60mm-650mm.

RF Plate Flange Thickness:14mm-46mm.

Specification:

Norminal
Diamete

Pipe Outside
Diameter

PN1.6MPa RF Plate Flange

Flange OD

Flange ID

Bolt Hole
Spacing

Flange
Thickness

Diameter of
Bolt Hole

10

14

90

15

60

14

14

15

18

95

19

65

14

14

20

25

105

26

75

16

14

25

32

115

33

85

16

14

32

38

140

39

100

18

18

40

45

150

46

110

18

18

50

57

165

59

125

20

18

65

76

185

78

145

20

18

80

89

200

91

160

20

18

100

108

220

110

180

22

18

125

133

250

135

210

22

18

150

159

285

161

240

24

22

200

219

340

222

295

26

22

250

273

405

276

355

28

26

300

325

460

328

410

32

26

350

377

520

381

470

35

26

400

426

580

430

525

38

30

450

480

640

485

585

42

30

500

530

715

535

650

46

33
