DRG
0.4
0.66
Vertical Type
Open
Copper
SASO, CE, RoHS, CSA, ISO9001, CB, UL, CCC
CCS, EC, BV, ABS, BV.
63072000
High Quality Drg Series Electric Heating Hot Water
0.44
Instant Heating Type
Pressurized
Digital Display
Plastic
DEYUAN MARINE
China
Type | DRG Series | |||||
Capacity(M3) | 0.12 | 0.2 | 0.3 | 0.5 | 1.0 | |
Working pressure(Mpa) | 0.4 | |||||
Design Pressure(Mpa) | 0.44 | |||||
Test Pressure(Mpa) | 0.66 | |||||
Safety valve open pressure(Mpa) | 0.42 | |||||
Water inlet Temp. | 15 | |||||
Water outlet Temp. | 65 | |||||
Hot water capacity(kg/h) | 180 | 360 | 540 | 720 | 900 | |
Electric Heating power(KW) | 12 | 24 | 36 | 48 | 60 | |
The laying of the outer surface of insulation layer thickness(mm) | 40 | |||||
Outsourcing galvanized steel sheet thickness(mm) | 0.7 | |||||
Power supply | AC380V,50HZ,3phase or AC440V,60HZ,3phase | |||||
Weight (kg) | 198 | 243 | 299 | 308 | 513 | |
DN | 400 | 500 | 600 | 700 | 900 | |
A | 608 | 708 | 808 | 908 | 1108 | |
B | 688 | 790 | 911 | 824 | 1072 | |
H | 1241 | 1335 | 1417 | 1773 | 2090 | |
d1 | DN25 | DN32 | DN40 | |||
d2 | 3/4″ | 1″ | ||||
b | 393 | 445 | 516 | 469 | 617 | |
h1 | 271 | 266 | 321 | 440 | 533 | |
h2 | 540 | 580 | 630 | / | / | |
C | 320 | 330 | 370 | 490 | 630 |
