Zyg Series Marine Combination Pressure Water Tank

  • ZYG
  • 0.44
  • Instant Heating Type
  • Pressurized
  • Digital Display
  • Plastic
  • SASO, CE, RoHS, CSA, ISO9001, CB, UL, CCC
  • CCS, EC, BV, ABS, BV.
  • 0.4
  • 0.66
  • Vertical Type
  • Open
  • Copper
  • Marine
  • DEYUAN MARINE
  • China
Product Feature:
1. High quality.
2. Competitive price.
3. Latest technology
4. Ample supply and prompt delivery.

Specification:
ZYG Series Combination Pressure Water Tank
This series of pressure water tank is suitable for ship fresh water pipes and sea water pipes, pumps; Pressure swith, electric control box and hydrophone are installed together.
It is compact and beautiful appearance. Easy to install and maintain, and it is an ideal unit for water supply system.
Main technical requirements:

Model ZYG Series
0.120.20.30.511.52
Volume(m3)0.120.20.30.511.52
Working pressure(MPa)0.4
Design pressure (MPa)0.44
Test pressure (MPa)0.66
Take-off pressure of safety valve(MPa)0.42
Working temperature)0~45
Design temperature50
Water pumpModel1.5CWX-1.5/1.5A1.5CWX-2/2A1.5CWX-3/3A
Flow rate(m3/h)36.510
Pumping head (m)404040
Power(kW)2.234
Model                 ZYG Series
0.12 0.2 0.3 0.5 1 1.5 2
Volume(m3) 0.12 0.2 0.3 0.5 1 1.5 2
Working pressure(MPa) 0.4
Design pressure (MPa) 0.44
Test pressure (MPa) 0.66
Take-off pressure of safety valve(MPa) 0.42
Working temperature() 0~45
Design temperature( 50
Water pump Model 1.5CWX-1.5/1.5A 1.5CWX-2/2A 1.5CWX-3/3A
Flow rate(m3/h) 3 6.5 10
Pumping head (m) 40 40 40
Power(kW) 2.2 3 4
