DEYUAN MARINE
bilge marine oily water separator
bilge marine oily water separator
less than 15ppm
Less that 0.25MPa
5°C-40°C
Electric heating (electric heater power is 2kW)
1.5kW
380v/50hz 440v/60hz
Standard expert package
20 days after deposit payment
High quality bilge marine oily water separator 2 M3/H oil water separator
2.0M3/H Oil Water Separator
1. Can endure the hull's libration as the ship is sailing and other local livration that is caused by other machines,
2. Should work functionally as the working medium temperature is between 5 and 40°C
3. Should work functionally when the relative humidity of the air environment is less than 90%
4. Energy sources should be offered,which is used for the demand of the electric piston pump and the electric heater and so on.
5.Pressure air for three-way air valve should be offered, the pressure range is from 0.6MPa to 0.8MPa.
15ppm Oily Water Separators
15ppm Bilge Separator is the professional equipment used to treat bilge water, which is composed of electrical control system and poston pump, and discharged water treated by the separator satisfy stated discharge standard. The equipment structure is reasonable and tightness, convenient for installation and maintenance.
Type | DY-0.25 | DY-0.5 | DY-1.0 | DY-1.50 | DY-2.0 | DY-2.5 | DY-3.0 | DY-4.0 |
Rated capacity (M3/H) | 0.25/0.31 | 0.5/0.62 | 1.0/1.25 | 1.5/1.87 | 2/2.25 | 2.5/3.12 | 3/3.75 | 4.0/5.0 |
Power (kw) | 0.75 | 1.10 | 1.10 | 1.10 | 2.20 | 2.20 | 3.0 | 3.0 |
Steam heater M2/kw | --- | --- | 1/30 | 1.5/45 | 2/60 | 2.5/75 | 3/90 | 4/120 |
15ppm Bilge alarm | including | including | including | including | including | including | including | including |
base | #5 | #6 | #6 | #8 | #8 | #8 | #10 | #10 |
Dimension | 1000*600*1320 | 1100*690*1460 | 1050*1084*1500 | 1100*1130*1660 | 1900*1120*1700 | 1700*1500*1900 | 2400* 1700*2020 | 2500* 2000*1820 |
Dry weight/ Net weight | 300/450 | 600/800 | 800/860 | 1060/1810 | 1260/ 2260 | 1500/ 2800 | 1800/ 3200 | 2100/ 3900 |
Suitable for vessels | <1000 DWT | 1000~5000 DWT | 5~10 KDWT | 10~30 KDWT | 30~50 KDWT | 50~100 KDWT | 100~200 KDWT | 100~300 KDWT |
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Kitty
E-mail: sales7[at]deyuanmarine[dot]com
Skype:marinesales6
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: + 86 - 13427793868
Web: http://www.deyuanmarine.com
