YWC-4.00 Model 15PPM Oil Ballast Water Separator


  • China (Mainland)


  • YWC--4.00

  • Wooden case packaging.

  • About 15 to 30 days.


YWC-4.00 Model 15PPM Oil Ballast Water Separator :

1.Rated capacity: 4.00 m3/h

2.Certificate: BV,EC,CCS and GL certificate available. delivery.

4.Good after-service.

It is a kind of environmental protection product designed based on international maritime IMO.MEPC.107(49) standard,the oil content in effluent water equal or less than 15ppm.The resolution made the fully new requirement referring to 15ppm bilge treatment plant in Annex I of MARPOL73/78.
The OWS type oily water separator can effectively dispose all kinds of bilge water including fuel oil, high-density residual oil and emulsion mixture combined with black ferric oxide and surfactant.
This OWS can also be used in industrial and petroleum, besides in ship vessels. The effluent oil content from OWS can meet any standards of Environment Bureau in China.

There are nine types of specifications in OWS series. The smallest type is OWS-0.25 which can be installed on ship less than 1000DWT .The biggest type is OWS-5.00 which can be installed on ship more than 300 thousand DWT. All of type drawings and devices are approved by China Classification Society for type test.The types and specifications are as follows:We can also design and produce the special type of Oily Water Separator according to the demands of our customers.


The device adopts the combination of 1st stage, cone plate gravity and coalesce separation; 2nd stage, fiber filter and 3rd stage, membrane permeation in order to make the treated bilge water to reach the requirements of discharge standard of the resolution of IMO MEPC.107 (49).


We not only offer marine equipment,but also provide after asles service. .
