High Quality Pneumatic plane-move accommodation ladder winch with CCS Certificate
1.Pneumatic plane-move accommodation ladder winch.
2.Working load:8~16KN.
3.Rope Dia.:9~13mm.
4.Certificate:CCS,EC,BV,ABS,NV,RINA.
Pneumatic plane-move accommodation ladder winch
Mainly used for handling accommondation ladders on oil vessels as
well as hoisting and sliding the pilot ladders.Driven by pneumatic motor,
the winch enjoys great reliability and security.
Working load | Support load | Rope dia | Pneumatic motor | Air press | Hoisting speed | |
8~12KN | 24~36KN | Φ9-11mm | power | 3.5~5.5ps | 0.5~0.7 (Mpa) | 3.5~10m/min |
Air comsuption | 3.5~5.5 m3/min | |||||
13~16kN |
39~48KN | Φ12~13mm | power | 5.5~7ps | ||
Air comsuption | 5.5~7 m3/min | |||||

|
