Electric life/rescue boat winch
* Item:electric life boat winch.
* Working load:25KN~138KN.
* Hoisting speed:≥36m/min.
electric life/rescue boat winch
This winch compiles with requirements of SOLAS new regulation,international life-saving appliance regulation MSC.48(66) international life –saving appliance test
MSC.81(70) and the lifeboat/rescue boat winch technology performance requirements(ISO6067)
type | Working load | Hoisting load(kn) | Hoisting speed | Descending rope speed | motor |
D25Z | 25 KN | 20KN | ≥36 | 90-110 | 12.5/12.5 |
D40Z | 40 KN | 20 KN | ≥36/10 | 80-90 | 16.8/16.8 |
D42Z | 42 KN | 21 KN | ≥36/10 | 80-110 | 15 |
D50Z | 50 KN | 28 KN | ≥36/10 | ≤78 | 20/7.5 |
D63Z | 63 KN | 30 KN | ≥36/10 | 90-110 | 22.5/10.6 |
D100Z | 100 KN | 55/70 KN | ≥36/8 | 90-120 | 42/20 |
PW100Z | 100 KN | 60/100 KN | ≥18/8 | 50-60 | 22.5 |
PW138Z | 138 KN | 80/138 KN | ≥18/8 | 40-60 | 30 |
